YAMAHA YG12 YS12 W轴旋转塑胶轮KG2-M9108-11 调宽转动皮带轮
KHY-M9113-00 PULLEY 1,MOTOR 1
2 KHY-M9117-00 SPLINE 1 1
3 KHY-M9118-00 BRACKET F,COLLAR 1
4
KHY-M9121-00 FRAME,CONVEYOR 2 L=1250
KHY-M9121-10 FRAME,CONVEYOR 2 L=1460
5
KHY-M9123-00 GUIDE 1 4 L=1250
KHY-M9123-10 GUIDE 1 1 L=1460
6
KHY-M9124-00 PLATE 1,GUIDE 2 L=1250
KHY-M9124-10 PLATE 1,GUIDE 1 L=1460
7
KHY-M9125-00 PLATE 2,GUIDE 2 L=1250
KHY-M9125-10 PLATE 2,GUIDE 2 L=1460
8
KHY-M9126-00 GUIDE 1-1 4 L=1250
KHY-M9126-10 GUIDE 1-1 2 L=1460
9
KHY-M9129-00 BELT 1,CONVEYOR 2 L=1250
KHY-M9129-10 BELT 1,CONVEYOR 1 L=1460
10 KHY-M912A-00 BRKT.,SENSOR 1
11 KHY-M9135-00 PLATE,EDGE 2 8
11-1 KHY-M9135-00 PLATE,EDGE 2 16 (2008/9/29) ME90125
12 KHY-M9136-00 PLATE,EDGE 3 8
12-1 Delete (2008/9/29) ME90125
13 KHY-M9157-00 SHAFT,MOTOR 1
14 KG2-M9105-00 PULLEY 1,SPLINE 1
15 KG2-M9108-11 COLLAR,CONVEYOR 2
16 KHY-M9111-00 BRKT.1,SPLINE 1
17 KGA-M9113-00 GUIDE 1,END 2
18 KGA-M9114-00 GUIDE 2,END 2
19 KGK-M9170-00 DC MOTOR ASSY. 1
20 KGT-M9193-00 NUT PLATE 4
21 KGY-M9140-A0 PULLEY,CONV. ASSY 4
22 KH2-M9105-11 PULLEY,MOTOR:P30-3GT 2
23 KV1-M9140-A0 PULLEY CONV.ASSY. 4
24 KV7-M9140-A0 PULLEY CONV.ASSY. 2
25 90990-28J076 WASHER 2
26 91312-03006 BOLT HEX.SOCKET HEAD 16 M3X6
27 91312-03008 BOLT HEX.SOCKET HEAD 46 M3X8
28 91312-03010 BOLT HEX.SOCKET HEAD 8 M3X10
29 91312-04010 BOLT HEX.SOCKET HEAD 8 M4X10
30 91312-04012 BOLT HEX.SOCKET HEAD 10 M4X12
31 91312-05020 BOLT HEX.SOCKET HEAD 2 M5X20
32 91317-04055 BOLT HEX.SOCKET HEAD 4 M4X55
33 92902-03200 WASHER PLAIN 16
34 92902-04200 WASHER PLAIN 3
35 92902-05200 WASHER PLAIN 8
36 92902-05600 WASHER PLAIN 4
37 92A08-04303 SET SCREW 4
38 98702-03005 SCREW FLAT HEAD 32
39 KH2-M9121-00 BEARING
|
